Earthmoving – Dozers

Dimensions
A
Length W/ Blade
22.41ft in

B
Width Over Tracks
8.6ft in

C
Height To Top Of Cab
11.09ft in

D
Length Of Track On Ground
9.32ft in

E
Ground Clearance
1.37ft in

F
Length W/O Blade
15.52ft in

Undercarriage
G
Track Gauge
6.57ft in

H
Standard Shoe Size
22.05in

Number Of Shoes Per Side
39

Ground Pressure
8.4psi

Number Of Carrier Rollers Per Side
2

Ground Contact Area
4930.56in2

Number Of Track Rollers Per Side
7

Track Pitch
8.51in

Specifications
Engine
Number Of Cylinders
6

Engine Make
2238

Engine Model
S6D125E

Gross Power
228hp

Power Measured @
2000rpm

Max Torque
737.3lb ft

Displacement
930.1cu in

Torque Measured @
1400rpm

Aspiration
Turbocharged

Operational
Operating Weight
53881lb

Fuel Capacity
126.9gal

Cooling System Fluid Capacity
20.9gal

Engine Oil Capacity
7.2gal

Hydraulic Fluid Capacity
26.7gal

Powertrain Fluid Capacity
23.8gal

Final Drives Fluid Capacity
10.9gal

Operating Voltage
24V

Transmission
Transmission Type
TF

Number Of Forward Gears
3

Number Of Reverse Gears
3

Max Speed – Forward
3.8mph

Max Speed – Reverse
4.9mph

Hydraulic System
Pump Type
Gear -type pump

Relief Valve Pressure
2773.6psi

Pump Flow Capacity
51.3gal/min

Standard Blade
Width
12.3ft in

Height
54.8in

Capacity
6.9yd3

Cutting Depth
21.3in
